12W KSAP0121200100VE Switching Power Adapters with 12VDC 1A CB , CE Safety Approval for Mobile Devices ADSL Pos

12W KSAP0121200100VE Switching Power Adapters with 12VDC 1A CB , CE Safety Approval for Mobile Devices ADSL Pos

  • 12W KSAP0121200100VE Switching Power Adapters with 12VDC 1A CB , CE Safety Approval for Mobile Devices ADSL Pos
12W KSAP0121200100VE Switching Power Adapters with 12VDC 1A CB , CE Safety Approval for Mobile Devices ADSL Pos
Product Details:
Place of Origin: China Mainland
Certification: CB , CE
Model Number: 12W KSAP0121200100VE
Payment & Shipping Terms:
Minimum Order Quantity: 1000pcs
Price: Negotiable
Packaging Details: PE bag + White box
Delivery Time: 35days
Payment Terms: T/T
Supply Ability: 1Million/Month
Contact Now
Detailed Product Description
High Light:

switching mode power adapter

,

switching adaptor power supply



12W KSAP0121200100VE Switching Power Adapters with 12VDC 1A   CB , CE Safety Approval for Mobile Devices ADSL Pos Set-top-box,UL90650 approval



Brand Name:
Input: •Input Voltage :  90 to 264 VAC
•Frequency :      47-50/60-63hz
•Input current :  0.4A (Max) 100 /240VAC
•Inrush current : 60A Max. 120VAC at max Load
                  100A Max.240VAC at max Load
•Leakage current: 0.25 mA Max
Output: •Over voltage protection
•Over current protection
 at 250% of lo and Auto-recovery
•Electronic short circuit protection
•Operating temperature 0~40℃ Free convection
•Operating humidity 10-90% RH Non Condensing
•Sea level Non-operating temperature -20~ 80℃
Safety standards: •Information technology equipment
•IEC/EN 60950-1, UL 60950-1, CSA C22.2
 No. 60950-1-03
Certificates and approvals: •CB , CE
EMI Emission: •Radiation Test&Conduction Test :EN 55022/FCC Part 15
•Harmonic Test : EN 61000-3-2
•Flicker  Test : EN 61000-3-3
EMS immunity: •ESD   Test:EN 61000-4-2
•RS    Test:EN 61000-4-3
•EFT   Test:EN 61000-4-4
•Surge Test:EN 61000-4-5
•CS    Test:EN 61000-4-6
•DIP   Test:EN 61000-4-11
Key Applications: Key features of KSAP0121200100VE
•Light, extra slim, sleek, compact design
•Green power, full complies with CEC level V, MEPS IV EUP2011
•High power density
•Extra safe design, have got their respective safety approvals
•Completed protect function

Key Applications of KSAP0121200100VE
•It’s suitable for an extremely wide range of applications, including:
•Mobile Devices
•ADSL
•Pos
•Set-top-box
Payment Details: •Payment Terms: T/T,negotiable for OEMs
Main Export Markets: • Eastern Europe
• North America
• Mid East/Africa
• Central/South America
• Asia
• Western Europe
• Australasia
