300 VAC 3A 36W Constant Voltage Waterproof LED Driver Full Range For CCTV Camera

300 VAC 3A 36W Constant Voltage Waterproof LED Driver Full Range For CCTV Camera

  • 300 VAC 3A 36W Constant Voltage Waterproof LED Driver Full Range For CCTV Camera
  • 300 VAC 3A 36W Constant Voltage Waterproof LED Driver Full Range For CCTV Camera
  • 300 VAC 3A 36W Constant Voltage Waterproof LED Driver Full Range For CCTV Camera
  • 300 VAC 3A 36W Constant Voltage Waterproof LED Driver Full Range For CCTV Camera
  • 300 VAC 3A 36W Constant Voltage Waterproof LED Driver Full Range For CCTV Camera
300 VAC 3A 36W Constant Voltage Waterproof LED Driver Full Range For CCTV Camera
Product Details:
Place of Origin: China
Brand Name: DongDaHua
Certification: CE,RoHS
Model Number: PF-36-12
Payment & Shipping Terms:
Minimum Order Quantity: 10
Price: /
Packaging Details: as for your requirement
Delivery Time: as per your order quantity
Payment Terms: TT,paypal
Supply Ability: 4000pcs/Day
Contact Now
Detailed Product Description
Product Name: Constant Voltage LED Driver DC Output Power: 36W
DC Output Voltage: 12V 24V Waterproof Grade: IP67
Input Voltage Range: 110-240V AC Input Frequency Range: 47Hz~63Hz
High Light:

12 volt led driver

,

constant voltage led drivers

Withstand 300VAC Constant Voltage LED Driver 36W 3A For Moving Sign



Quick detail:

Power: 36W

Input: AC110-264V

Output: DC 12V 24V

Size:  146*39*30

Certificate: CE&ROHS

Warranty: 2 years



Description:

1. Protections :Short circuit/Overload/Over temperature

2. Cooling by free air convection

3. IP67 design for indoor or outdoor installations

4. 100% full load burn-in test

5. Suitable for LED lighting

6. Products through CE& ROHS certification

7. Two years warranty



Descriptions:



Parameter

Model: PF-36

DC output voltage

12V±5%

24V±5%

Rated output current

3A

1.5A

Output current range

0-3A

0-1.5A

Ripple and Noise

120mVp-p



DC output power

36W

36W

Efficiency

85%

85%

Input voltage range

110-240V AC

Short-circuit protection

Damage free short-circuit protection 3 times or more with automatic restoration

Overload protection

105-150% hiccup with automatic restoration

Temp.coefficient

±0.03%℃ ( 0-40℃ )

Voltage tolerance

Input-output range: 1.5KvAC

Working environmental temp.

-10℃~+40℃

Waterproof grade

IP67

Input frequency range

47Hz~63Hz

Storage temperature

-20℃~+85℃

Dimension

151*42*30mm

weight

0.28 kg



Features:

1. Constant voltage design

2. Universal AC input/Full range

3. Withstand 300VAC surge input for 5 seconds

4. Epoxy encapsulated with IP67 level

5. Protections:Short circuit/Overload/Over voltage

6. Cooling by free air convection

7. Small and compact size

8. Fully isolated plastic case

9. Suitable for LED lighting and moving sign applications

10. 100% full load burn-in test

11.  Low cost,high reliability

12. 2 years warranty



300 VAC 3A 36W Constant Voltage Waterproof LED Driver Full Range For CCTV Camera



Application:

It’s suitable for an extremely wide range of applications, including:
LED, CCTV camera;
Communications and security products;
LED Strip Lighting/ LED lamp / LED Light, LED / LCD display.





300 VAC 3A 36W Constant Voltage Waterproof LED Driver Full Range For CCTV Camera 0





Quality assurance:

300 VAC 3A 36W Constant Voltage Waterproof LED Driver Full Range For CCTV Camera 1




Delivery:


300 VAC 3A 36W Constant Voltage Waterproof LED Driver Full Range For CCTV Camera 2
