Automatic Desktop Switching Power Supply 24V 6A For LED Display

Automatic Desktop Switching Power Supply 24V 6A For LED Display

  • Automatic Desktop Switching Power Supply 24V 6A For LED Display
  • Automatic Desktop Switching Power Supply 24V 6A For LED Display
  • Automatic Desktop Switching Power Supply 24V 6A For LED Display
  • Automatic Desktop Switching Power Supply 24V 6A For LED Display
  • Automatic Desktop Switching Power Supply 24V 6A For LED Display
Automatic Desktop Switching Power Supply 24V 6A For LED Display
Product Details:
Place of Origin: Shenzhen,China
Brand Name: RAYTOP
Certification: CE, RoHS, FCC
Model Number: ETZ2400600
Payment & Shipping Terms:
Minimum Order Quantity: 1K
Price: Negotiable
Packaging Details: White box/Master Carton
Delivery Time: 15-20 work days.
Payment Terms: T/T, L/C
Supply Ability: 200,000 Pcs monthly.
Contact Now
Detailed Product Description
AC Cable: 1.2M Application: LED Display|LED Light|LCD TV
Approval: CE|RoHS|FCC|UL|SAA Cable Material: Copper
DC Cable: 1.2M EMI Standards: FCC Part 15B
Color: Black Input: AC100-240V
Output: 24V 6A Output Power: 150W
Plug: EU|UK|US|CCC|SAA Product Name: AC To DC Power Adapter
Protection: Short Circuit|Over Voltage|Over Current Frequency: 50Hz / 60Hz
Operating Temperature: 0~40℃
High Light:

external power supply

,

external power supply



Automatic Desktop Switching Power Supply 24V 6A For LED Display



Specs:



Input: AC100-240V, 0.2A max.

Frequency: 50/60Hz

Output: DC24V, 6.0A

DC Cable: 16AWG, Copper, length: 1.2M

Plug: EU, UK, US, SAA, CCC

Color:Black



Features:



- Worldwide voltage input;

- High efficiency:>83%;

- Protection: Short circuit protection, over voltage protection, over current protection.

- MTBF: 50,000 hours.

Approval: CE, RoHS, FCC

- Warranty: 2 years



Description:



This is an AC power adapter, desktop adapter, come with single output tip 5.5x2.1x10mm. It has high efficiency as well as steady performance. The tip size and plug type can be changeable.

Note: indoor use only.



Packing Details:



Packaging Details: PACKING OPTIONS:
1)White box

2)Master Carton
3) OEM Package Design
Delivery Detail: Shipped in 15 days after payment



Applications:



This desktop switching power supply is used for LCD TV, LCD Display, LED Lights, Security and Protection Products etc.



Specifications:











Input

Rated Input Voltage

AC100~240V

Input Voltage Range

AC 90~264V

Rated Frequency

50/60 Hz

Input Frequency Range

47~63 Hz

Input AC Current

0.2A

Inrush Current

30A













Output

Rated Output Voltage

DC24V

Rated Output Current

6000mA

Rated Power

150W

Ripple and Noise

150mV p-p

Standby Power Consumption

0.5W

Turn-on

5s

Hold-up

20s

Over Voltage Protection

Yes

Over Current Protection

Yes

Short Circuit Protection

Yes, automatically recover after short circuit removed.











Reliability

Hi-pot

3000Vac

Insulation Resistance

Input to output at 500Vdc

Leakage Current

10mA

EMI Standards

FCC Part 15B Class B

RoHS Compliant

Yes

MTBF

50,000 hours

Burn-in

40+/-5 ℃, full load, 4 hours

Drop Test

6 direction, each one time from height 1.0M





Environmental

Operating Temperature

0~40℃

Operating Humidity

10~80%

Storage Temperature

-20~65℃

Storage Humidity

0~90%

Safety Approvals

CE, RoHS, FCC, UL, SAA

Warranty

2 Years





Competitive Advantage:



- Open private model w/o extra cost for you;

- 0.3% free backup of order quantity;

- Direct factory price without middle man.

- High performance-to-price ratio;

- Perfect after-sale service



Tag:desktop switching power ,power adapter,power supply,automatic power adapter
