Product Details:
Place of Origin: Shenzhen,China
Brand Name: RAYTOP
Certification: CE, RoHS, FCC
Model Number: ETZ12001000
Payment & Shipping Terms:
Minimum Order Quantity: 1K
Price: Negotiable
Packaging Details: White box/Master Carton
Delivery Time: 15-20 work days.
Payment Terms: T/T, L/C
Supply Ability: 200,000 Pcs monthly.
Contact Now
Detailed Product Description
Application: LCD TV Approval: CE|RoHS|FCC|UL|SAA
Cable Material: Copper DC Cable: 1.2M
Function 1: 1a Desktop Power Supply Function 2: 12v Adapter Charger
Function 3: 12w Switching Adapter Reference: 12w 12v 1a
High Light:

external power supply

,

ac power adapters

Factory direct sale Desktop power Adapter12V1000mA, Two ends cable power supply





Quick Detail:



Function 1:1a desktop power supply

Function 2:12v adapter charger

Function 3:12w switching adapter

Reference:12w 12v 1a



Specs:



Input: AC100-240V, 0.2A max.

Frequency: 50/60Hz

Output: DC12V, 1A

DC Cable: 22AWG, Copper, length: 1.2M

Plug: EU, UK, US, SAA, CCC



Features:



- Worldwide voltage input;

- High efficiency:>83%;

- Protection: Short circuit protection, over voltage protection, over current protection.

- MTBF: 50,000 hours.



Approval: CE, RoHS, FCC

Warranty: 1years



Description:



This is an AC power adapter, desktop adapter, come with single output tip 5.5x2.1x10mm. It has high efficiency as well as steady performance. The tip size and plug type can be changeable.

Note: indoor use only.



Applications:



Widely used for Router, POS System, Security Cameras, Tablets etc.



Specifications:



Input

Rated Input Voltage

AC100~240V

Input Voltage Range

AC 90~264V

Rated Frequency

50/60 Hz

Input Frequency Range

47~63 Hz

Input AC Current

0.2A

Inrush Current

30A

Output

Rated Output Voltage

DC12V

Rated Output Current

1000mA

Rated Power

24W

Ripple and Noise

150mV p-p

Standby Power Consumption

0.5W

Turn-on

5s

Hold-up

20s

Over Voltage Protection

Yes

Over Current Protection

Yes

Short Circuit Protection

Yes, automatically recover after short circuit removed.

Reliability

Hi-pot

3000Vac

Insulation Resistance

Input to output at 500Vdc

Leakage Current

5mA

EMI Standards

FCC Part 15B Class B

RoHS Compliant

Yes

MTBF

50,000 hours

Burn-in

40+/-5 ℃, full load, 4 hours

Drop Test

6 direction, each one time from height 1.0M

Environmental

Operating Temperature

0~40℃

Operating Humidity

10~80%

Storage Temperature

-20~65℃

Storage Humidity

0~90%

Safety Approvals

CE, RoHS, FCC, UL, SAA

Warranty

2 Years





Competitive Advantage:



- Open private model w/o extra cost for you;

- 0.3% free backup of order quantity;

- Direct factory price without middle man.

- High performance-to-price ratio;

- Perfect after-sale service
