Internet 240V AC Wall Mount America Power Adapter 9V 2A 18W ESD / CAS

Internet 240V AC Wall Mount America Power Adapter 9V 2A 18W ESD / CAS

  • Internet 240V AC Wall Mount America Power Adapter 9V 2A 18W ESD / CAS
  • Internet 240V AC Wall Mount America Power Adapter 9V 2A 18W ESD / CAS
  • Internet 240V AC Wall Mount America Power Adapter 9V 2A 18W ESD / CAS
  • Internet 240V AC Wall Mount America Power Adapter 9V 2A 18W ESD / CAS
Internet 240V AC Wall Mount America Power Adapter 9V 2A 18W ESD / CAS
Product Details:
Place of Origin: China
Brand Name: STARWELL
Certification: UL,CE,ROHS, FCC,GS,SAA,C-TICK
Model Number: SMS-01090200-S06US
Payment & Shipping Terms:
Minimum Order Quantity: 100pcs
Price: negotiation
Packaging Details: Carton box
Delivery Time: 10-15 days
Payment Terms: Ex works
Supply Ability: 1, 000, 000PCS/week
Contact Now
Detailed Product Description
High Light:

external power adapter

,

european power adapter





Internet 240V AC Wall Mount America Power Adapter 9V 2A 18W ESD / CAS





Feartures:



> input voltage range: 100~240VAC

> output: 9V 2A

> Effiency: 85% minimum

> Ripple and Noise: 80mV maximum

> Color: Black or white

> Dc cable length: 1.5 meters/1.2 meters

> DC jack: 5.5*2.1*10mm

> Weight: 100g

> AC Plug:  US , EU , AU ,UK plug avaliable

> Safety protection: over load, over voltage, short ciruict, open load protection.




Specifications:





Input Rated Voltage :

100Vac~240Vac

Input Frequency Range:

47Hz~63Hz

Input Inrush Current :

0.3A max

Efficiency  :

85%(MIN)at Rated Voltage

Output:

9V 2A

Output power :

18W

Ripple and Noise :

<80Mv at full road with 20MHz bandwidth

Turn On Delay Time:

<3S  (AC:110V and full load)

Safety protection :

over voltage and current protection.

Leakage Current:

<5mA

USB connector:

5.5*2.1*10mm

Operating Temperature:

0°C----+60°C

Storage Temperature:

-20°C----+85°C

Certificate:

CE GS TUV UL/CUL FCC ROHS,SAA,PSE,C-TICK

Safety Standard :

EN60950-1 UL60950-1  ESD (EN61000 3-3)
CAS (60950 ITE/TE)  FCC Part 15 subpart B Class B
AN/NZS CISPR 22:2006

Application:

For battery charger, mobile phone, cell phone, iphone etc…





 Model List:

  18W SERIES



Model Input Voltage Power Output Voltage Output Current Plug type
SMS-01070200-S06EU 100-240VAC 14W 7V 2A EU,US,UK,AU
SMS-01070200-S06US
SMS-01070200-S06UK
SMS-01070200-S06AU
SMS-01090200-S06EU 100-240VAC 18W 9V 2A EU,US,UK,AU
SMS-01090200-S06US
SMS-01090200-S06UK
SMS-01090200-S06AU
SMS-01120150-S06EU 100-240VAC 18W 12V 1.5A EU,US,UK,AU
SMS-01120150-S06US
SMS-01120150-S06UK
SMS-01120150-S06AU
SMS-01150100-S06EU 100-240VAC 15W 15V 1A EU,US,UK,AU
SMS-01150100-S06US
SMS-01150100-S06UK
SMS-01150100-S06AU
SMS-01180100-S06EU 100-240VAC 18W 18V 1A EU,US,UK,AU
SMS-01180100-S06US
SMS-01180100-S06UK
SMS-01180100-S06AU
SMS-01050300-S06EU 100-240VAC 15W 5V 3A EU,US,UK,AU
SMS-01050300-S06US
SMS-01050300-S06UK
SMS-01050300-S06AU
SMS-01240075-S06EU 100-240VAC 18W 24V 0.75A EU,US,UK,AU
SMS-01240075-S06US
SMS-01240075-S06UK
SMS-01240075-S06AU





DRAWING:



Internet 240V AC Wall Mount America Power Adapter 9V 2A 18W ESD / CAS 0





Internet 240V AC Wall Mount America Power Adapter 9V 2A 18W ESD / CAS 1



EMC Standards & Safety Standards / EMC Standards





1.1.    EMC Standards



GB9254

GB17625.1

GB13837

FCC- Part15

EN 55022

EN55024

CISPR 22

EN 61000-4-4

EN 61000-3-2

EN 61000-3-3

EN 61000-4-2

EN 61000-4-3

EN 61000-4-5

EN 61000-4-6

EN 61000-4-8

EN 61000-4-11





1.2.    Safety Standards



Type

Country

Standard

Type

Country

Standard

CCC

China

GB4943

CE

Europe

EN60950-1

CCC

China

GB8898

CB

CB

IEC60950

UL/CUL

USA

UL60950-1

C-TICK

Australia

AS/NZ60950

KC

Korea

KC60950

GS/TUV

German

EN60950





INSTRUCTION:



- The apparatus shall not be exposed to dripping or splashing and that no objects filled with liquids,

such as vases, shall be placed on the apparatus.

- The mains plug is used as the disconnect device, the disconnect device shall be readily operable.

- The socket-outlet shall be installed near the equipment and shall be easily accessible.

- No naked flame source, such as lighted candles, should be placed on the apparatus.

- Maximum operating ambient for the equipment is 40℃.

- The apparatus should not be used in a confined space such as a bookcase.

- This appliance is not intended for use by persons (including children) with reduced physical,

sensory, or mental capacities, or lack of experience and knowledge, unless they have been given

supervision or instruction concerning use of the appliance by a person responsible for their Safety.

- Children should be supervised to ensure that they do not play with the appliance.
