Home Products12 Volt LED Power Supply

36w desktop power adapter

36w desktop power adapter

  • 36w desktop power adapter
  • 36w desktop power adapter
  • 36w desktop power adapter
  • 36w desktop power adapter
  • 36w desktop power adapter
Product Details:
Place of Origin: China
Brand Name: BTB
Certification: CE CB UL FCC SAA GS ROHS CCC KC
Model Number: B-001500200
Payment & Shipping Terms:
Minimum Order Quantity: 1000PCS
Price: 4-10
Packaging Details: standard packing
Delivery Time: 1-3weeks
Payment Terms: T/T,L/C,Western union,Cash,Paypal
Supply Ability: 3500000
Contact Now
Detailed Product Description

36w desktop power adapter



Input 100 to 240V AC, 50/60Hz
Output power 12W24w36w72w90w120w
Output voltage 12VDC
Output current 1A/2A3A/4A/5A/6A/8a/10a
Color available Purple ,red ,orange ,yello ,blue,silver etc
Outlet single usb ,dual usb or with cable
Protection Overload protection
Output over voltage protection
Short circuit protection
Certificate CEC power supply standard
CE approved (EMC, TVD)
KC
PSE
ROHS
FCC
Efficiency Mini 75 %
Standard DC Connector Micro USB & Mini USB & iPhone 30Pin & 2.0*0.7 & 2.5*0.75 &
3.5*1.35 & 4.0*1.7 &5.5*2.1 &5.5*2.5
No Load Power Consumption ≤0.3W at Rated Voltage
Ripple And Noise Output voltage 1%
High-Voltage test Primary to secondary: 3 kV 5 mA 60S
Leakage Current 0.5 mA(max) at input 240V AC
Operating Temperature Range 0--40°C
Storage Temperature Range -20 --- 85°C
High Humidity Operation + 40 °C and 90 ~ 95% Humidity
Dimension 72.5mm*48mm*29mm
Net weight USBAbout 65 gram per unit
MTBF 50,000 hours
Insulation Resistance:Primary to Secondary 50 Meg. Ohms min. 500VDC
Application Mobile phone, Tablet PC, Bluetooth headset, MID,Water purifier, LED, Medical machine,CCTV camera, LCD, Set-top box, DVR, Router, Modem,etc.
Packing A Qty: 100PCS/CTN
MEA: L46.5*W34*H14.5cm
Packing Material:PE bag+white box+carton
Packing B Qty: 100PCS/CTN
MEA: L47cm*W38cm*H25cm
Packing Material:PE bag+Paper segment+carton
Packing c Qty: 100PCS/CTN
MEA: L43.5cm*W35.6cm*H27cm
Packing Material:Blister+carton

36w desktop power adapter 00000

36w desktop power adapter 2

36w desktop power adapter 3

 36w desktop power adapter 436w desktop power adapter 5

 36w desktop power adapter 6

 36w desktop power adapter 7
