7 Volt 2.5 Amp EU Wall Mount Power Adapter EN60950-1 CE UL FCC EMC





7 Volt 2.5 Amp EU Wall Mount Power Adapter EN60950-1 CE UL FCC EMC





Feartures:



> output:7V 2.5A

> Color: Black or white

> Effiency: 85% minimum

> Weight: 100g

> input voltage range: 100~240VAC

> Dc cable length: 1.5 meters / 1.2 meters

> Ripple and Noise: 80mV maximum

> DC jack: 5.5*2.1*10mm / 5.5*2.5*10mm

> AC Plug:  US , EU , AU ,UK plug avaliable

> Safety protection: over load, over voltage, short ciruict, open load protection.





Specifications:



Input Rated Voltage :	100Vac~240Vac
Input Frequency Range:	47Hz~63Hz
Input Inrush Current :	0.3A max
Efficiency  :	85%(MIN)at Rated Voltage
Output:	7V 3A
Output power :	21W
Ripple and Noise :	<80Mv at full road with 20MHz bandwidth
Turn On Delay Time:	<3S  (AC:110V and full load)
Safety protection :	over voltage and current protection.
Leakage Current:	<5mA
USB connector:	5.5*2.1*10mm
Operating Temperature:	0°C----+60°C
Storage Temperature:	-20°C----+85°C
Certificate:	CE GS TUV UL/CUL FCC ROHS,SAA,PSE,C-TICK
Safety Standard :	EN60950-1 UL60950-1  ESD (EN61000 3-3) CAS (60950 ITE/TE)  FCC Part 15 subpart B Class B AN/NZS CISPR 22:2006
Application:	For battery charger, mobile phone, cell phone, iphone etc…





 Model List:

12W SERIES
Model	Input Voltage	Power	Output Voltage	Output Current	Plug type
SMS-01090100-S04EU	100-240VAC	9W	9V	1A	EU,US,UK,AU
SMS-01090100-S04US
SMS-01090100-S04UK
SMS-01090100-S10AU
SMS-01100100-S04EU	100-240VAC	10W	10V	1A	EU,US,UK,AU
SMS-01100100-S04US
SMS-01100100-S04UK
SMS-01100100-S10AU
SMS-01050200-S04EU	100-240VAC	10W	5V	2A	EU,US,UK,AU
SMS-01050200-S04US
SMS-01050200-S04UK
SMS-01050200-S10AU
SMS-01060200-S04EU	100-240VAC	10W	6V	2A	EU,US,UK,AU
SMS-01060200-S04US
SMS-01060200-S04UK
SMS-01060200-S10AU
SMS-01120100-S04EU	100-240VAC	10W	12V	1A	EU,US,UK,AU
SMS-01120100-S04US
SMS-01120100-S04UK
SMS-01120100-S10AU
SMS-01240050-S04EU	100-240VAC	10W	24V	0.5A	EU,US,UK,AU
SMS-01240050-S04US
SMS-01240050-S04UK
SMS-01240050-S10AU





18W SERIES
Model	Input Voltage	Power	Output Voltage	Output Current	Plug type
SMS-01070200-S06EU	100-240VAC	14W	7V	2A	EU,US,UK,AU
SMS-01070200-S06US
SMS-01070200-S06UK
SMS-01070200-S06AU
SMS-01090200-S06EU	100-240VAC	18W	9V	2A	EU,US,UK,AU
SMS-01090200-S06US
SMS-01090200-S06UK
SMS-01090200-S06AU
SMS-01120150-S06EU	100-240VAC	18W	12V	1.5A	EU,US,UK,AU
SMS-01120150-S06US
SMS-01120150-S06UK
SMS-01120150-S06AU
SMS-01150100-S06EU	100-240VAC	15W	15V	1A	EU,US,UK,AU
SMS-01150100-S06US
SMS-01150100-S06UK
SMS-01150100-S06AU
SMS-01180100-S06EU	100-240VAC	18W	18V	1A	EU,US,UK,AU
SMS-01180100-S06US
SMS-01180100-S06UK
SMS-01180100-S06AU
SMS-01050300-S06EU	100-240VAC	15W	5V	3A	EU,US,UK,AU
SMS-01050300-S06US
SMS-01050300-S06UK
SMS-01050300-S06AU
SMS-01240075-S06EU	100-240VAC	18W	24V	0.75A	EU,US,UK,AU
SMS-01240075-S06US
SMS-01240075-S06UK
SMS-01240075-S06AU





24W SERIES
Model	Input Voltage	Power	Output Voltage	Output Current	Plug type
SMS-01050400-S06EU	100-240VAC	20W	5V	4A	EU,US,UK,AU
SMS-01050400-S06US
SMS-01050400-S06UK
SMS-01050400-S06AU
SMS-01070300-S06EU	100-240VAC	21W	7V	3A	EU,US,UK,AU
SMS-01070300-S06US
SMS-01070300-S06UK
SMS-01070300-S06AU
SMS-01090300-S06EU	100-240VAC	27W	9V	3A	EU,US,UK,AU
SMS-01090300-S06US
SMS-01090300-S06UK
SMS-01090300-S06AU
SMS-01120200-S06EU	100-240VAC	24W	12V	2A	EU,US,UK,AU
SMS-01120200-S06US
SMS-01120200-S06UK
SMS-01120200-S06AU
SMS-01240100-S06EU	100-240VAC	18W	24V	1A	EU,US,UK,AU
SMS-01240100-S06US
SMS-01240100-S06UK
SMS-01240100-S06AU



  36W SERIES

Model	Input Voltage	Power	Output Voltage	Output Current	Plug type
SMS-01050500-S06EU	100-240VAC	25W	5V	5A	EU,US,UK,AU
SMS-01050500-S06US
SMS-01050500-S06UK
SMS-01050500-S06AU
SMS-01090400-S06EU	100-240VAC	36W	9V	4A	EU,US,UK,AU
SMS-01090400-S06US
SMS-01090400-S06UK
SMS-01090400-S06AU
SMS-01120300-S06EU	100-240VAC	36W	12V	3A	EU,US,UK,AU
SMS-01120300-S06US
SMS-01120300-S06UK
SMS-01120300-S06AU
SMS-01180200-S06EU	100-240VAC	36W	18V	2A	EU,US,UK,AU
SMS-01180200-S06US
SMS-01180200-S06UK
SMS-01180200-S06AU
SMS-01240150-S06EU	100-240VAC	18W	24V	1.5A	EU,US,UK,AU
SMS-01240150-S06US
SMS-01240150-S06UK
SMS-01240150-S06AU





DRAWING:











EMC Standards & Safety Standards / EMC Standards





1.1.    EMC Standards



GB9254	GB17625.1	GB13837	FCC- Part15
EN 55022	EN55024	CISPR 22	EN 61000-4-4
EN 61000-3-2	EN 61000-3-3	EN 61000-4-2	EN 61000-4-3
EN 61000-4-5	EN 61000-4-6	EN 61000-4-8	EN 61000-4-11

1.2.    Safety Standards



Type	Country	Standard	Type	Country	Standard
CCC	China	GB4943	CE	Europe	EN60950-1
CCC	China	GB8898	CB	CB	IEC60950
UL/CUL	USA	UL60950-1	C-TICK	Australia	AS/NZ60950
KC	Korea	KC60950	GS/TUV	German	EN60950





INSTRUCTION:



- The apparatus shall not be exposed to dripping or splashing and that no objects filled with liquids,

  such as vases, shall be placed on the apparatus.

- The mains plug is used as the disconnect device, the disconnect device shall be readily operable.

- The socket-outlet shall be installed near the equipment and shall be easily accessible.

- No naked flame source, such as lighted candles, should be placed on the apparatus.

- Maximum operating ambient for the equipment is 40℃.

- The apparatus should not be used in a confined space such as a bookcase.

- This appliance is not intended for use by persons (including children) with reduced physical,

   sensory, or mental capacities, or lack of experience and knowledge, unless they have been given

   supervision or instruction concerning use of the appliance by a person responsible for their Safety.

- Children should be supervised to ensure that they do not play with the appliance.
