5W 9V 1500MA / 1.5A Universal AC Power Supply Adapter For POS , Laptop Battery Adapter
Quick Detail:
-
9V 1500MA 1.5A Universal AC Power Supply Adapter for POS
-
Type: wall mount type
-
Certificate: CE & RoHS
-
OEM/ODM welcome
-
Dc plug: 5.5*2.1mm,5.5*2.5mm,3.5*1.35mm, micro/mini usb etc.
-
100% aging test before shipment
-
12 months warranty for after-sales-service
Description:
Features:
1.Good comparison between quality and price.
2.High reliability and low noise.
3.Fully plastics case.
4.Internal over voltage,over current and short-circuit protection.
5.Automatic recovery after normalization
o Universal Input 100~240VAC 50/60Hz
o Small volume, light weight, high efficiency.
o Cooling by free air convection.
o 100% Full load burn-in test.
o One year warranty.
o Output Voltage: 9V
o Output Current: 1500mA
o Power: 5Watt
o Ripple & Noise: 1% of Output Voltage
o Leakage Current: 0.25mA
o No load power Consumption
o Working Temperature:0-40°C Max
o Efficiency:78%Min
o Weight: 90g
o Dimensions: 75 x 29x 43.0 mm
High working effciency
Serious aging test for a few hours before packing to make sure reliable quality
One year warranty with satisfying after-sales service
Our own factory production, wholesale price to help you win the market
o Accurate information and descriptions.
o All orders are shipped on time.
o All items are fully inspected prior to shipping to meet international standards by our QC staffs.
o All items are with CE RoHS approval to ensure the products quality.
Specification:
|
lnput voltage:
|
AC 100-240V
|
|
Frenquency:
|
50-60 hz
|
|
Starting lash current:
|
40A/230VAC
|
|
Output voltage:
|
DC 9V
|
|
Output current:
|
1500mA
|
|
Voltage precision:
|
+5%-3%
|
|
Ripplesnoise (mVp-p):
|
<1% output voltage
|
|
Iinear adjustment rate:
|
±0.5%MAX
|
|
Temperature index:
|
±0.02%
|
|
Starting time:
|
below 1S(240V input,l.=100%)
|
|
Over-loading protection:
|
115%-150% rated power
|
|
Short circuit protection and it can automatic recovery after normalization
|
|
Form of cooling is natural cooling
|
|
Weight:
|
90g
|
How to Install?
-
Connect power supply to the supplied unit.
-
Power supply must be connected to a working electrical AC line with a voltage of 100-240V.
-
Do not install power supply in locations with high humidity, dust or strong direct sunlight.
-
The power supply should be installed in a location with good airflow.
-
Power supply can only be installed indoors.
Applications:
1. CCTV security, door access, digital camera, etc.
2. POS machine, mini printing machine, etc.
3. Electronic scale, flowerpot etc.
4. LED strip, LED lighting etc.
