Short Circuit Wall Mount Power Adapter 16V 2A FCC Part 15 Class B For Cannon Printer

Product Details:

Place of Origin:	Shenzhen,China
Brand Name:	RAYTOP
Certification:	CE, RoHS, FCC
Model Number:	RT-WMA-1600200

Payment & Shipping Terms:

Minimum Order Quantity:	1 PCS
Price:	US$1.9-2.3 per unit
Packaging Details:	White box, Color Box or Blister, 200 PCS/Carton
Delivery Time:	15-20 working days
Payment Terms:	T/T, L/C, Western Union
Supply Ability:	200,000 Pcs monthly.

Contact Now

Detailed Product Description

Style:	Wall Mount Power Supply	Used For:	Adapter For Security Access Control
Output:	16V 2A	Input:	AC100-240V
Function 1:	Charger For Security Camera	Function 2:	Charger For Security Appliance
Function 3:	Charger For Security Alarm System
High Light:	ac to dc power converter , wall plug adapter

100-240VAC Input EU Plug 16V 2A Wall-mount Power Adapter RCA Jack for Santral

Description:

This is an true power high frequency switching mode power adapter 16V 2A, with excellent quality in conformity with CE, RoHS, FCC standard.

Input: AC100-240V, 50/60Hz, 500mA max.

Output: DC16V, 2000mA

DC Tip: RCA Jack

AC Plug: EU 2 Pin;

DC Cable: 20AWG, 1.2M

Protections: Short circuit, over voltage, over current protections

Features:

-High efficiency:>82%;

-Protection: Short circuit protection, over voltage protection, over current protection.

-Long lifespan;

-2 Years warranty.

-Approval: CE, RoHS, FCC

Specifications:

Input	Rated Input Voltage	AC100~240V
	Input Voltage Range	AC 90~264V
	Rated Frequency	50/60 Hz
	Input Frequency Range	47~63 Hz
	Input AC Current	500mA
	Inrush Current	30A
Output	Rated Output Voltage	DC16V
	Rated Output Current	2000mA
	Rated Power	32W
	Ripple and Noise	150mV p-p
	Standby Power Consumption	0.5W
	Turn-on	5s
	Hold-up	20s
	Over Voltage Protection	Yes
	Over Current Protection	Yes
	Short Circuit Protection	Yes, automatically recover after short circuit removed.
Reliability	Hi-pot	3000Vac
	Insulation Resistance	Input to output at 500Vdc
	Leakage Current	5mA
	EMI Standards	FCC Part 15B Class B
	RoHS Compliant	Yes
	MTBF	50,000 hours
	Burn-in	40+/-5 ℃, full load, 12 hours
	Drop Test	6 direction, each one time from height 1.0M
Environmental	Operating Temperature	0~40℃
	Operating Humidity	10~80%
	Storage Temperature	-20~65℃
	Storage Humidity	0~90%
Safety Approvals	CE, RoHS, FCC, UL, SAA
Warranty	2 Years

Applications:

This power adapter has vase application such as Set top Box, Massager, Car refrigerator, Water dispenser, Cable television, Optical transmitter and receiver, Scanner, Santral etc.
